technicaldatasheets

13 / 24

Marlin NanoLube™
TECHNICAL INFORMATION
NANO OIL-DRILLING LUBRICANT - NL40110
NANO OIL-DRILLING LUBRICANT TYPICAL RESULTS
1. Minimizes torque requirements, drag and pipe sticking.
2. Energy reduction
DIRECTIONS (SHAKE WELL BEFORE USE)
NanoLube Oil-Drilling Lubricant can be used at dilutions of 0.5% to 3.0% depending on the severity of the
operation.
NanoLube Oil-Drilling Lubricant is a highly concentrated
lubricant that increases the lubricity of all oil-based
fluids. It is insoluble in hydrocarbons, but completely
miscible with all oils including synthetics. NanoLube Oil-
Drilling Lubricant preferentially adsorbs on and bonds
with metal surfaces when present in an oil or oil/water
emulsion thereby vastly improving the fluid’s lubricity. It
is a completely biodegradable product that minimizes
rotational torque, drag and pipe sticking tendency.
NanoLube Oil-Drilling Lubricant forms a thick tenacious
film that withstands high compression forces, masking
surface roughness and thereby imparting extreme-
pressure lubricating properties to the mud. It contains
surfactants that provide both boundary and extreme
pressure lubrication making NanoLube Nano-Drilling
Lubricant effective over a wide range of loading
conditions.
Minor additions of Oil-Drilling Lubricant are extremely
effective at reducing the coefficients of frictions (COF) for
all oil-based fluids thereby providing optimum wellbore
lubricity, reducing torque, drag, differential sticking
tendency of the drill string. NanoLube Nano-Drilling
Lubricant is effective in all oil based systems, including
synthetic oils, without any adverse effects on fluid
properties.
Available: NL401110-5 5 gallon $2,260/GAL
APPLICATIONS
FEATURES
nitrites, heavy metals, phenols, nor diethanolamine
BENEFITS
SPECIFIC GRAVITY @ 60°F 0.910
PH, 5% IN DI WATER 9.6
POUNDS PER GALLON 7.7
COLOR AMBER
Warranty: All products purchased from Nano Lube Corporation are subject to terms and conditions set out in the contract, order acknowledgment and/or bill of
lading. Nano Lube Corporation warrants only that its product will meet those specifications designated as such herein or in other publications. All other infor-
mation supplied by Nano Lube Corporation is considered accurate but is furnished upon the express condition that the customer shall make its own assessment
to determine the product’s suitability for a particular purpose. No warranty is expressed or implied regarding such other information, the data upon which the
same is based, or the results to be obtained from the use thereof; that any product shall be merchantable or fit for any particular purpose, or that the use of
such other information or product will not infringe any patent. PRICES SUBJECT TO CHANGE WITHOUT NOTICE
NanoLube™
