Marlin NanoLube

marlinnanolube.com

TECHNICAL INFORMATION

NANOLUBE METALFORM - NL52190

METALFORM TYPICAL RESULTS

1. 400% increase in parts produced with single application to die

2. 10% energy reduction in punch press operation (22 ton press)

3. Eliminated scratching, galling, marring, orange peel on metal surfaces

4. 20% increase rate of part production

DIRECTIONS (

SHAKE WELL BEFORE USE)

NanoLube MetalForm can be blended at 5% to 30% volume with virtually any oil-based metal working

or die lubricant to significantly increase its load-bearing capacity, reduce damage to metal being

worked.

NanoLube Metalform is our concentrated extreme

pressure product to be blended with existing die

lubricants to significantly increase extreme pressure, anti

-wear properties.

NanoLube Metalform ,contains no chlorine or sulfur, and

because of its outstanding performance characteristic can

also be blended at 5% to 30% volume with virtually any

oil-based metalworking or die lubricant to significantly

increase its load-bearing capacity, reduce damage to

metal being worked.

NanoLube Metalform works on ferrous and non-ferrous

metals, on polymer or other non-metal surfaces as well.

Reduces galling, marring, scratching, orange-peel effect,

breaking of metal being formed or stamped. Reduces

energy requirements. One application to a die generally

allows for production of multiple parts before recoating.

NanoLube Metalform has good rust protection, excellent

boundary lubrication, good anti-weld properties which

prevent galling on the tool point and finished work

surfaces: this has a vital effect on the finished product.

NanoLube Metalform is stable and low odor. Will not

attack paint, exotic metals, bearings or pumps.

Available: NL52190 1 gallon pail $480/GAL

APPLICATIONS

-casting

FEATURES

orange peel effect on material surfaces

BENEFITS

SPECIFIC GRAVITY @ 60°F

0.907

FLASH POINT °F

>375

POUNDS PER GALLON

7.55

COLOR

AMBER

Warranty: All products purchased from Nano Lube Corporation are subject to terms and conditions set out in the contract, order acknowledgment and/or bill of

lading. Nano Lube Corporation warrants only that its product will meet those specifications designated as such herein or in other publications. All other infor-

mation supplied by Nano Lube Corporation is considered accurate but is furnished upon the express condition that the customer shall make its own assessment

to determine the product’s suitability for a particular purpose. No warranty is expressed or implied regarding such other information, the data upon which the

same is based, or the results to be obtained from the use thereof; that any product shall be merchantable or fit for any particular purpose, or that the use of

such other information or product will not infringe any patent. PRICES SUBJECT TO CHANGE WITHOUT NOTICE

NanoLube
