Marlin NanoLube
™
marlinnanolube.comTECHNICAL INFORMATION
EXTREME HIGH-PRESSURE GREASE - NL00550
EXTREME HIGH-PRESSURE GREASE TYPICAL RESULTS
Smoother Action; eliminated scratching, galling, marring
Will usually take 20 minutes to penetrate metal pours and will improve with operational usage.
DIRECTIONS
Use NanoLube Extreme High-Pressure Grease same as you would conventional grease
NanoLube Extreme High Pressure Grease is the latest
technological advance in grease.
Although NanoLube Extreme High Pressure Grease is the
premium grease for all applications, whether on-road, off
-road, lake, or salt water, it can also be used as an
industrial grease with excellent shear stability, load
carrying ability, water resistance, rust resistance and
oxidation resistance.
NanoLube Extreme High Pressure Grease is free of heavy
metals and resists burning.
NanoLube Extreme High Pressure Grease will provide
excellent performance in severe high temperatures
applications, with light or heavy loads, and under wet or
dry conditions.
NanoLube Extreme High Pressure Grease is compatibility
with a wide variety of seal materials, such as Nitrile,
Viton and Neoprene.
Available:
NL00550-14 14oz tubes $20/EA
NL00550-35 35lbs pail
$692/EA
APPLICATIONS
-Duty Fleets
FEATURES
-LB Standards
BENEFITS
Grease
maintenance costs
SPECIFIC GRAVITY @ 60°F
0.98
FLASH POINT °F
>480
FIRE POINT, °F, ASTM D92
>520
THICKENER
CALCIUM SULFONATE
NLGI, CONSISTANCY GRADE, ASTM D217
2
TEXTURE
SMOOTH
DROPPING POINT °F, ASTM D2265
>600
PENETRATION UNWORKED, ASTM D217
285
100,000 STROKES CHANGE FROM 60 STROKES
±20
WHEEL BEARING LEAKAGE, GM, ASTM D1264
0.4
TIMKEN OK LOAD, LBS, ASTM D2509
70
WATER SPRAY-OFF, %, MAX, ASTM D4049
7.2
OIL SEPARATION, 25°C, 24HRS, %, ASTM D1742
0
OXIDATION STABILITY, PSI DROP 100HRS, ASTM D942
1.5
FOUR BALL EP, WELD, KGF, ASTM D2596
800
FOUR BALL EP WEAR SCAR, MM, ASTM D2266
0.40
DI RUST PREVENTION, ASTM D1743
PASS
OIL VISCOSITY @ 40°C, cSt, ASTM D445
460
VISCOSITY INDEX, ASTM D2270
97+
POUNDS PER GALLON
8.16
COLOR
Aqua Green
